Ayzeze: Safely charging your e-bike or e-scooter
• Don’t leave your battery unattended while charging, when you're out or while you're asleep
• Don’t cover chargers or battery packs when charging
• Don’t overload sockets or use unsuitable extension chords
• Don’t charge or store batteries in direct sunlight or in areas with temperatures above 45⁰C
• Don’t charge batteries next to combustible materials or hazardous substances
• Always unplug your charger once you have finished charging
• Always make sure to only use the proper proprietary charger
• Always ask a professional when converting your e-bike or e-scooter
• Always check your battery (and charger) for visible damage
-----
⚠️Note: In accordance with regulations in certain countries, the packaging label must not exceed 250W; please refer to the product manual for actual specifications.
⚡ 1400W High-Power Motor for Enhanced Speed and Powerful Climbing
This scooter is equipped with a high-performance 1400W motor, delivering powerful acceleration and excellent climbing ability, ensuring a faster, smoother, and more dynamic riding experience.
🔋 48V 20Ah Large Capacity Battery, Range up to 70 km
Equipped with a large-capacity 48V 20Ah battery, it offers a range of up to 70 km on a single charge, making it ideal for daily commuting and long-distance rides.
⚙️ Front and Rear Dual Disc Brakes for Safety
The front and rear dual disc brake system provides responsive and stable braking force, enhancing control and safety even when riding at high speeds.
🌄 Front and Rear 2000 lb Spring Suspension for Ultimate Comfort
Featuring heavy-duty 2000 lb spring suspension on both the front and rear, it effectively absorbs shocks and bumps, making rides smoother and more comfortable on all terrains.
🛴 One-Step Folding Design for Easy Portability and Storage
The scooter features a convenient one-step folding mechanism that allows for quick folding in seconds, making it compact and easy to carry, store, or transport in tight spaces.
🗒️ Specifications
Brand: OOTD
Model: SR1
Frame Material: Aluminum Alloy
Motor: 1400W
Battery: 48V 20Ah
Battery Charger: 54.6V 2A
Charging Time: 9-10 hours
Maximum Speed: Factory limited to 25 km/h, up to 50 km/h after speed limit removal
Range: 70 km
(Specific range is affected by various factors such as rider weight, weather temperature, riding speed, and road conditions.)
Throttle: Thumb Throttle
Suspension: Front and Rear 2000 lb Spring Suspension
Brakes: Front and Rear Disc Brakes
Tires: 10-inch Tubeless Tires
Climbing Angle: ≤20°
Rider Height: 160 cm - 200 cm
Load Capacity: 120 kg
Net Weight: 26.26 kg
Package Weight: 30 kg
Product Dimensions: 122.5 × 64.6 × 125.5 cm
Package Dimensions: 123.5 × 20.5 × 61 cm
📦 Package Contents
1 x OOTD SR1 Electric Scooter
1 x Charger
1 x User Manual
