Mini USB Soldered Nano V3.0 16MHz 5V Micro Controller Module for Arduino CH340G
Description：
This is a brand new, sealed, high quality soldered Arduino Nano clone micro controller, which can be powered by a mini USB or onboard power from connections.
The 3.0 board is a small, complete, and breadboard-friendly board based on the ATmega328. It has similar functionality as the Due or R3, but in a smaller form factor.
A pre-installed bootloader to get you up & running quickly.
USB headers will be gold anodised or silver depending on availability.
USB cable can be in different colours black /BLUE, depending on availability. The picture is only for guidance.
The bootloader is already pre-installed. The CH340 is used to replace the FT232RL chip. Please install the CH340 driver before plugging this board into the computer.
Depending on your version of the Arduino IDE, there will be an option to select the processor ATmega328P with the old bootloader.
Specification:
Condition: New
Headers: Soldered
Connection Type: Mini USB
Version: 3.0
Controller: ATMEGA328P-AU
USB to Serial CHip: CH340
Processor: ATmega328P
Clock Speed: 16MHz
Input Voltage (Recommended): 7V-12V
Operating Voltage: 5V
DC Current per I/O Pin: 40mA
Features:
8x Analog Input Ports: A0 - A7
