CT312 TIG MMA CUT TIG-Welder Inverter Welding Machine Multifunction 120A TIG/ MMA 30A Plasma Cutter 3 in 1 220V

Features:

1. TIG-Welder: 10-120A DC TIG Electric Current Output. Quality TIG welding on stainless steel, nickel alloys, copper, brass and bronze etc. HF start improvers tungsten life.

2. Plasma Cutter: 30AMP Plasma Cutter Current Output. Compact Plasma Cutter Has a Handle for Portability and Uses Non-Hazardous Compressed Air to Cut Stainless Steel, Alloy Steel, Mild steel, Copper, and Aluminum ect.

3. Stick/MMA-Welder: 10-120AMP DC Stick/MMA Electric Current Output; Easy ARC Start, Stable Welding Arc, Deep Weld Pool and Beautiful Welding Shape; Adjustable Hot Striking Arc Current Which Can Greatly Improve the Arc-Starting Function; Suitable for Welding with Different Kinds Basic Electrode.

4. Small size, light weight, energy saving and no noise Small splashing,great penetration, easy and simple to operate and aesthetic appearance of weld seam Over-voltage protection, under voltage protection, over current protection, over load protection. Automatic compensation for voltage fluctuation

5. Air cooling, thermostatic protection, suitable for DIY.

Specification:

Model Number: CT312

Rated output voltage: 220V ±15%

Weight: 28.66lb

Pulse Frequency: 50/60Hz

Rated Duty Cycle: 60 %

Dimensions: 340 x 160 x 240mm

Technology: Latest invert technology

Application TIG CUT MMA

Input current 10 15.87 14.7

Output current 15 92 25

Current range 10-120 10-30 10-120

Package Included:

1 x 2.5M TIG Torch

1 x 2.5M Cutting Torch (PT31)

1 x 1.5M MMA Clamp & Cable

1 x 1.5M Ground Clamp & Cable

1 x Air Regulator

1 x Consumables 3sets
