[OMNI Wheel Robot Car - Omnidirectional Movement] This robot car is a platform robot equipped with state-of-the-art 4-wheel drive Mecanum wheels. Unlike conventional wheels, Mecanum wheels (OMNI wheels) are powerful wheels that allow robots to move not only forward and backward, but also left and right, rotate, and even move diagonally at 45°. They can easily turn around even in narrow spaces and are now commonly used in unmanned robots, platform cars, towing tractors, and autonomous trucks, and are frequently seen in robot competitions.
[App-Controlled, Easy and Fun Project] This Arduino robot car has smart modes such as simulated driving, WIFI control, and autonomous driving. Using the Android and iOS app, you can control the OSOYOO Onim Wheel robot car with your smartphone. In addition, various interesting smart functions such as line tracking, obstacle avoidance, and gravity-sensing vehicle control can be implemented.
【High Quality & Professional】 Our company is Canada's only Science Fair supplier. Circuit Builder is a manufacturer of IoT, autonomous machines, home appliances, Arduino, and Micro:Bit products. We are always committed to improving our manufacturing precision and quality, and we are now a STEM company with engineers and programmers from all over the world, including Japan, the United States, China, and Canada. We will work hard to provide robot programming learning kits that will not disappoint you. Thank you for your support.
[High-Value Robot Kit] This Arduino Robot Car Kit includes all the parts you need to build your own robot, including the latest Mecanum wheels, motors, WIFI shield, Arduino circuit board, USB cable, Model Y motor driver module, ultrasonic sensor, Bluetooth module, servo motor, tracking sensor, voltmeter (2), battery box, charger, and more. Unleash your imagination; with this one kit, you can create countless types of robots. It's a truly cost-effective DIY robot kit.
[Detailed Instructions - Beginners Welcome] For beginners, detailed instructions are available at osoyoo.com/ja/?p=43404 (Japanese, with program). Access your web browser and download the manual. It includes everything from simple installation instructions to wiring diagrams, codes, and instructional videos. Even those with no prior programming experience can easily build a robot car.
Metal Omnidirectional Mecanum Wheel Robot Kit (Applicable to Arduino Mega2560)
Lesson 1: Assembling a Mecanum Wheel Robot Car
Lesson 2: Obstacle Avoidance Robot
Lesson 3: Line Tracking
Lesson 4: Bluetooth Control
Lesson 5: WiFi Control
Cool, next-generation Mecanum wheels
A Mecanum wheel (also known as an omni wheel or iron wheel) is a special type of wheel in which barrels mounted at a 45° angle on the circumference of the wheel rotate freely. By controlling the rotation of each motor, it is possible to move in all directions without changing the orientation of the vehicle.
Because each wheel moves in a specific direction, this robot car can move in all directions—forward, backward, left, right, and diagonally (at a 45° angle)—without changing the orientation of the vehicle, allowing it to easily navigate any terrain. These wheels are particularly useful on sharp curves and narrow roads.
WIFI IoT device
In this mode, the robot car is set up as a WiFi hotspot, and once you connect your mobile device (such as a smartphone) to the same LAN (Local Area Network), you can control the robot car with an app. With the IoT becoming increasingly widespread, you can experience a home AI robot that you can control with just the touch of your finger.
Simulated driving (Bluetooth control)
In this mode, you control the robot car by simulating real driving using iOS or Android apps. Bluetooth control is a common control method in robot competitions.
This app has a steering wheel and gears just like a real car, so you can experience real driving.
A learning kit and a robot toy—the perfect gift.
The OSOYOO Arduino Mecanum Wheel Robot Car Kit is a learning kit that brings together robotics, Arduino, programming, and electrical/electronic engineering. In this era of rising STEM education, this is the perfect gift for anyone interested. Moreover, as artificial intelligence becomes more widespread, the future is unpredictable, but this knowledge will be a valuable asset for life.
Experimental Learning: Build Your Own Robot
Let's build an auto robot car by referring to the wiring diagrams and circuit diagrams in the detailed manual. Through this, you can learn about assembling electronic devices and programming robots. Whether you want to study robot programming or are a parent who wants to pique your child's interest in STEM, our Arduino Mecanum Wheel Robot Car Kit is a kit that allows you to learn while playing.
specification
Mecanum wheels
Diameter: 80mm
Width: 40mm
Number of barrels: 9
Body material: Aluminum alloy
Barrel material: PP + PE
Weight capacity: 15kg (per wheel)
encoder
Connector: JST XH 6pin (1.5mm)
Black: VM motor power supply
Red: GND
White: V-type power supply for Hall sensors
Yellow: G-GND for Hall sensor
Orange: S1 Hall sensor
Green: S2 Hall sensor
Standard operating conditions: Rated voltage: DC 9.0V
Gear ratio: 1/75
Motor no-load speed: 11500±10% rpm
No-load current: max. 180mA (DC power supply)
Stall current: Maximum 4500mA (DC power supply)
Stall torque: 160 g.cm (torque measurement)
