Sensor length [mm]: 96
Manufacturer's index: 106876
Degree of protection (IP): IP65
Sensor width [mm]: 30
Ambient temperature under operating conditions [°C] up to: 70
Ambient temperature under operating conditions [°C] from: -25
Sensor height [mm]: 33.3500
Rated operational current Ie for AC-15, 125 V [A]: 6
Rated operational current Ie for AC-15, 230 V [A]: 6
Rated operational current Ie for AC-15, 24 V [A]: 6
Rated operational current Ie for DC-13, 125 V [A]: 0.8000
Rated operational current Ie for DC-13, 230 V [A]: 0.3000
Rated operational current Ie for DC-13, 24 V [A]: 3
CN: 85365080
Length: 95
EAN: 4015081066391
Explosion protection category for gases: None
Explosion protection category for dust: None
Number of auxiliary safety contacts: 0
Number of changeover contacts: 0
Number of normally closed contacts: 1
Number of normally open contacts: 1
Material Housing: Plastic
Housing according to standard: Yes
Suitable for safety applications: Yes
PKWiU: 27.33.11.0
Housing coating: Other
Type of switching element: Slow-break contact
Type of interface: None
Type of interface with safety function: None
Type of housing construction: Cuboid
Type of electrical connection: Metric cable gland
Series: LS
Width: 35
Weight: 0.0800
Forced disconnection: Yes
Height: 30
With status indicator: No
